Desk mounting your Console Server
To prepare the Console Server for use on a desk use the four self-adhesive rubber feet
provided with the unit. Stick the four feet to the underside of the unit, one in each corner,
approximately one inch from each adjacent edge.
1 inch
(2.5 cm)
1 inch
(2.5 cm)
bottom panel
of unit
rubber foot
rubber foot
