Admin port – Black Box 16 port User Manual
Page 130
Black Box Console Server user guide
130
Admin Port
The port labelled ‘Admin’ is on the rear of the unit. When fitted with a 25-pin female
D-type connector the wiring is as follows:
If you wish to connect a terminal into the Admin Port, see the connection example in
Pin
Signal
Function
2
RXD
Receive
3
TXD
Transmit
7
S/GND
Signal Ground
all others
-
(do not connect)
