5. Configurator
Decorator position
The extra information can be place in the north, south, east or west of the projector pictograph.
Click on the desired radio button to determine the decorator position.
Decorator content
The following information can be displayed in the configuration preview:
•
Projector name
• Connection settings
• Lamp shutter status
• Active files
5.5 Reconnect a projector
Via the context menu
1. Right click on a not connected projector in the preview pane. (image 5-13)
A context menu opens.
2. Select Connect.
The projector tries to make a connection and to retrieve data. When it is successful the pictograph
border becomes green, the properties are filled out. When it is not successful, the border stays gray
and a projector not responding message is displayed.
Image 5-13
Connect projector via context menu
Via the menu
1. Select a not connected projector in the preview pane. (image 5-14)
2. Click Configuration on the menu and select Selected device → Connect projector.
The projector tries to make a connection and to retrieve data. When it is successful the pictograph
border becomes green, the properties are filled out. When it is not successful, the border stays gray
and a projector not responding message is displayed.
