8-1
Installation Mode
5976072 BARCOELM R12 05052000
8
INSTALLATION MODE
Installation Mode
Start Up
Push the cursor key é or ê to highlight 'Installation Mode' and then press ENTER.
ADJUSTMENT MODE
Select a path from below :
RANDOM ACCESS
INSTALLATION
SERVICE
Source 01
INSTALLATION
INPUT SLOTS
800 PERIPHERAL
CONFIGURATION
OSD COLOR
INTERNAL PATTERNS
NO SIGNAL
LENS
QUICK ACCESS KEYS
MENU POSITION [DEFAULT]
Select with é or ê
then
to return.
INPUT SLOTS
1. RGB-SS [CV]
2. RGB-SOG
3. Video [Video]
4. Component Video
5. SDI
6. SDI
Select with é or ê
then
to return.
menu 1
menu 2
The following items can be selected in the Installation mode :
Input slots : to set up the input priority.
800 Peripheral : to select the type of output module used in the RCVDS05.
Configuration : to set up the projector position.
OSD color : to change the color of the highlighted item.
No Signal : to display a black or blue screen when no source is connected to the projector or to set up the auto shutdown.
Internal Patterns
Lens adjustment
Overview of the Quick Access Keys.
Menu Position : default in the corner or in the center of the image.
Input Slots
What can be done ?
The input configuration of the variable inputs is shown in the input slots menu. These configuration can be changed.
To view or to change the input configuration :
1 Push the cursor key é or ê to highlight 'Input Slots'.
2 Press ENTER to select.
The internal system will scan the input slots and displays the result in the Input slots menu.
menu 2
Possible results for the input slots :
Source indication
Video or S-Video Video[Video]
Video[S-Video]
RGB analog RGB-SS[CV] : separate sync is composite video signal on H/C input
RGB-SS[CS or HS&VS] : separate sync is composite sync or horizontal and vertical sync
RGB-SOG : sync on green
menu 1
Select with é or ê
then
to return.
INSTALLATION
INPUT SLOTS
800 PERIPHERAL
CONFIGURATION
OSD COLOR
INTERNAL PATTERNS
NO SIGNAL
LENS
QUICK ACCESS KEYS
MENU POSITION [DEFAULT]
