Converged Enhanced Ethernet Administrator’s Guide 121
53-1002163-02
CEE map configuration
11
DRAFT: BROCADE CONFIDENTIAL
CEE Priority Table defines each CoS mapping to Priority Group, and completes PFC configuration.
There are eight rows in the CEE Priority Table.
Table 30 details the default CEE Priority Table
configuration.
Defining a priority group table
To define a priority group table map, perform the following steps from privileged EXEC mode.
1. Enter global configuration mode.
switch#configure terminal
2. Specify the name of the CEE map to define.
switch(config)#cee-map default
3. Define the CEE map for PGID 0.
switch(config-ceemap)#priority-group-table 0 weight 50 pfc
4. Define the CEE map for PGID 1.
switch(config-ceemap)#priority-group-table 1 weight 50
5. Enter the copy command to save the running-config file to the startup-config file.
switch(config)#do copy running-config startup-config
Defining a priority-table map
To define a priority-table map, perform the following steps from privileged EXEC mode.
1. Enter global configuration mode.
switch#configure terminal
2. Activate the CEE map mode.
switch(config)#cee-map default
3. Define the map.
switch(config-ceemap)#priority-table 1 1 1 0 1 1 1 15.0
4. Enter the copy command to save the running-config file to the startup-config file.
switch(config)#do copy running-config startup-config
TABLE 30 Default CEE priority table
CoS PGID
0 15.6
1 15.7
2 15.5
3 15.4
4 15.3
5 15.2
6 15.1
7 15.0
