22

FURNACE MAY NOT OPERATE
Failure to follow this caution may result in intermittent

furnace operation.
Furnace control must be grounded for proper operation or

else control will lock out. Control must remain grounded

through green/yellow wire routed to gas valve and manifold

bracket screw.

CAUTION

!

115--V WIRING
Verify that the voltage, frequency, and phase correspond to that

specified on unit rating plate. Also, check to be sure that service
provided by utility is sufficient to handle load imposed by this

equipment. Refer to rating plate or Table 7 for equipment

electrical specifications.

U.S. Installations: Make all electrical connections in accordance

with National Electrical Code (NEC) ANSI/NFPA 70--2008 and
any local codes or ordinances that might apply.

Canadian Installations: Make all electrical connections in

accordance with Canadian Electrical Code CSA C22.1 or
authorities having jurisdiction.

FIRE HAZARD
Failure to follow this warning could result in personal

injury, death, or property damage.
Do not connect aluminum wire between disconnect switch

and furnace. Use only copper wire.

!

WARNING

Use a separate, fused branch electrical circuit with a properly

sized fuse or circuit breaker for this furnace. See Table 7 for wire

size and fuse specifications. A readily accessible means of
electrical disconnect must be located within sight of the furnace.
NOTE: Proper polarity must be maintained for 115--v wiring. If
polarity is incorrect, control LED status indicator light will flash
rapidly and furnace will NOT operate.
J--BOX RELOCATION
NOTE
: If factory location of J--Box is acceptable, go to next
section (ELECTRICAL CONNECTION TO J--BOX).
NOTE: On 14--in. (356 mm) wide casing models, the J--Box
shall not be relocated to other side of furnace casing when the
vent pipe is routed within the casing.

1. Remove and save two screws holding J--Box.

NOTE: The J--Box cover need not be removed from the J--Box
in order to move the J--Box. Do NOT remove green ground
screw inside J--Box. The ground screw is not threaded into the
casing flange and can be lifted out of the clearance hole in casing
while swinging the front edge of the J--Box outboard of the
casing.

2. Cut wire tie on loop in furnace wires attached to J--box.
3. Move J--Box to desired location.
4. Fasten J--Box to casing with two screws removed in Step

1.

5. Route J--Box wires within furnace away from sharp edges,

rotating parts and hot surfaces.

ELECTRICAL CONNECTION TO J--BOX
Field--Supplied Electrical Box on Furnace J--Box Bracket
See Fig. 23.

1. Remove cover from furnace J--Box.
2. Attach electrical box to furnace J--Box bracket with at least

two field--supplied screws through holes in electrical box
into holes in bracket. Use blunt--nose screws that will not

pierce wire insulation.

3. Route furnace power wires through holes in electrical box

and J--Box bracket, and make field--wire connections in
electrical box. Use best practices (NEC in U.S. and CSA

C22.1 in Canada) for wire bushings, strain relief, etc.

4. Route and secure field ground wire to green ground screw

on J--Box bracket.

5. Connect line voltage leads as shown in Fig. 25.
6. Reinstall cover to J--Box. Do not pinch wires between

cover and bracket.

Electrical Box on Furnace Casing Side
See Fig. 23.

FIRE OR ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal

injury, death, or property damage.
If field--supplied manual disconnect switch is to be mounted

on furnace casing side, select a location where a drill or

fastener cannot damage electrical or gas components.

!

WARNING

1. Select and remove a hole knockout in the casing where the

electrical box is to be installed.

NOTE: Check that duct on side of furnace will not interfere with
installed electrical box.

2. Remove the desired electrical box hole knockout and

positionthe hole in the electrical box over the hole in the
furnace casing.

3. Fasten the electrical box to casing by driving two

fieldsupplied screws from inside electrical box into casing
steel.

4. Remove and save two screws holding J--Box. (See Fig.

22.)

5. Pull furnace power wires out of 1/2--in. (12 mm) diameter

hole in J--Box. Do not loosen wires from strain--relief
wire--tie on outside of J--Box.

6. Route furnace power wires through holes in casing and

electrical box and into electrical box.

7. Pull field power wires into electrical box.
8. Remove cover from furnace J--Box.
9. Route field ground wire through holes in electrical box

and casing, and into furnace J--Box.

10. Reattach furnace J--Box to furnace casing with screws

removed in Step 4.

11. Secure field ground wire to J--Box green ground screw.
12. Complete electrical box wiring and installation. Connect

line voltage leads as shown in Fig. 25. Use best practices
(NEC in U.S. and CSA C22.1 in Canada) for wire

bushings, strain relief, etc.

13. Reinstall cover to J--Box. Do not pinch wires between

cover and bracket.

313A
