REMOTE UNIT CONFIGURATION & OPERATION
35
8. Fine-tune the LF equalization to remove ‘black video smearing’ - black smears to the
right of large objects such as window title bars (see Figure 11).
LF Equalization Commands Key Sequence
Increase LF Equalization (Coarse)
Decrease LF Equalization (Coarse)
+
+
Increase LF Equalization (Fine)
Decrease LF Equalization (Fine)
+
+
9. Fine-tune the HF equalization to sharpen the video image. Increase HF Equalization
until a white edge to the right of small characters just starts to appear (see Figure 11).
HF Equalization Commands Key Sequence
Increase HF Equalization (Coarse)
Decrease HF Equalization (Coarse)
+
+
Increase HF Equalization (Fine)
Decrease HF Equalization (Fine)
+
+
On certain monitors, you may obtain a sharper image by
overcompensating HF EQ and then decreasing LF EQ to remove any
bright streaks.
10. If you are using one or more flat panel monitors in the Remote consoles, carry out auto-
adjustment again.
11. Save the settings by pressing the key. Alternatively, to discard any changes and
revert to the settings stored in the EEPROM, press + . The
Remote unit automatically exits Command Mode after 30 sec of inactivity and saves all
settings, including any changes.
