SERVSWITCH BRAND CATX KVM EXTENDER FAMILY
20
3.3 Remote Unit Installation
To install a Remote unit:
1. Switch off all devices.
2. Connect your keyboard, monitor(s) and mouse to the Remote unit as shown in
Figure 2.
These ports may also be attached to the CPU side of a KVM switch in
order to have a Remote CPU. However, if you are attempting to use the
extender between cascaded KVM switches this may not work. Please contact
Technical Support to discuss your application.
3. If appropriate, connect audio equipment and serial devices. Connect the audio cables as
follows:
RemoteUnit Audio Device
Audio Out Speakers
Audio In (MIC) Microphone
See Appendix E: Audio/Serial Ports, page 58 for further information.
4. Connect CATx cable(s) to the INTERCONNECT socket(s) on the front of the Remote
unit.
5. Connect the 9V power supply to power the unit.
!
