OVERVIEW
17
2.6 How to Use This Guide
This guide describes the installation and configuration of the ServSwitch Brand CATx
KVM Extender Series. Although the connection and operation of the system is relatively
straightforward, you should consider the following before getting started:
Connection & Compatibility
If you have purchased an Extender Kit, this will contain all the cables required to connect the
Local unit to your PC or KVM switch. The Remote console (keyboard, monitor and mouse)
and any audio and serial equipment connects directly to the Remote unit.
If you have purchased a Remote Unit, ensure that it is compatible with your Local unit (see
Compatibility, page 16).
For information about connection and installation, see
Installation, page 18.
Interconnection Cable
You will need CATx (any category 5, 5e, 6 or higher) cable, terminated with RJ45 plugs, to
connect the Local and Remote units (see Interconnection Cable Requirements, page 19.
Adjusting Video
Video signals become distorted when transmitted over CATx cables. To get the best from
your extender system, it is essential that you adjust the Remote unit to optimize the video
image quality:
• For experienced users, there is a Quick Setup section at the start of this guide (see page
10).
• For the full procedure, see Remote Unit Configuration & Operation, page 28.
• Refer to Appendix D: Advanced Cabling Issues (Skew), page 55 for a more in depth
discussion of skew correction and advanced cabling issues.
