SERVSWITCH BRAND CATX KVM EXTENDER FAMILY
16
2.5 Compatibility
Interface Compatibility
• PS/2 Keyboard: Compatible with all standard keyboards. Certain keyboards with
enhanced features may also be supported with custom firmware.
• PS/2 Mouse: Compatible with all standard 2-button, 3-button and wheel mice. To
connect to a PC which does not have a PS/2 mouse port, an active serial converter is
required – Model No: AC244A.
• Audio: Input and output are line-level. Amplified speakers are required. A micro- phone
may be directly connected to the Remote unit (optional pre-amplification).
• Serial: Transparent up to 19.2K Baud (38.4K operation may be possible with some
devices). The following serial signals are extended: TX, RX, RTS, CTS, DTR, DSR. In
rare cases, a wiring adaptor may be required to transfer RI and DCD.
• Video: VGA to UXGA. Separate sync, composite sync, or sync-on-green. Maximum
resolution and refresh rates depend on cable length and cable type (see Appendix G:
Specifications, page 61).
Extender Compatibility
The ServSwitch Brand CATx KVM Extender Series of CATx KVM extender products
offer enhanced performance while maintaining complete compatibility with existing
ServSwitch standalone and rack mount CAT5 extenders.
You can use CAT5 and CATx products belonging to the same family in any combination.
However, it is not possible to mix Standard and Audio products within a system. CATx units
are not currently compatible with SUN (ACU1004A, ACU1005A) or Serial only products
(ACU1002A, ACU1008A, ACUSREM, ACU1006SRA).
Standard Family Audio Family
Standard family units are compatible
with the following CAT5 products:
Audio family units are compatible with the
following CAT5 products:
ACU1001A ACU1009A ACU1022A ACU1028A
ACU3001A ACU3009A ACU3022A ACUVREM
ACU1049A ACUMREM ACUWREM ACU1006VRA
ACUREM ACUREMSW ACU1006DVRA ACU1006MRVA
ACU1006RA ACU1006DRA
ACU1012RA ACU1006MRA
