3-20 User’s Manual
M9
10. Align the notch of the memory module with that of the memory slot and
gently insert the module into the slot at about a 45 degree angle before
holding it down until the latches on either side snap into place.
Installing the memory module
11. Screw in the two screws and replace the memory module cover.
Slot A
■
Never allow metal objects, such as screws, staples and paper clips, to
enter the computer or keyboard. Foreign metal objects can create a
short circuit, which can cause computer damage and fire, possibly
resulting in serious injury.
■
Do not touch the connectors on the memory module or on the
computer. Debris on the connectors may cause memory access
problems.
■
The memory module cover will be hot after using the computer for long
periods of time. Exercise caution when removing.
■
The slot A is reserved for main memory. Use the slot B for expanded
memory. If only one card is installed, use the slot A.
■
Align the grooves along the edges of the memory module with the
locking tabs on the connector and insert the module into the connector
firmly - if you find it difficult to install the memory module, gently prise
the locking tabs outwards using the tip of your finger.
Please also ensure that you hold the memory module along its left and
right hand edges - the edges with the grooves in.
