PORTÉGÉ R200 4-12
Operating Basics
Dialing Properties
Select this item to display the dialing properties.
Connecting
To connect the modular cable(optional), follow the steps below.
1. Plug one end of the modular cable into the computer’s modem jack.
2. Plug the other end of the modular cable into a telephone jack.
Connecting the internal modem
If you are using the computer in Japan, the Telecommunications Business
Law requires that you select Japan region mode. It is illegal to use the
modem in Japan with any other selection.
The modular cable for connecting a modem should use a commercially
available cable. Connect the end of the modular cable with the core to the
computer.
■ Connection to any communication line other than an analog phone line
could cause a PC system failure.
■ Connect the built-in modem only to ordinary analog phone lines.
■ Never connect the built-in modem to a digital line (ISDN).
■ Never connect the built-in modem to the digital connector on a
public telephone or to a digital private branch exchange (PBX).
■ Never connect the built-in modem to a key telephone system for
residences or offices.
■ Never operate your PC on AC power during a thunderstorm. If you see
lightning or hear thunder, immediately turn off the PC. An electric surge
caused by the storm, may result in a system failure, loss of data or
hardware damage.
Modular cable
Telephone jack
Modem jack
Do not pull on the cable or move the computer while the cable is
connected.
