PORTÉGÉ R200 6-16
Power and Power-Up Modes
High Capacity 2nd Battery Pack
A High Capacity 2nd Battery Pack can increase the battery-based
operating time of the computer. To increase the battery-based operating
time, connect the High Capacity 2nd Battery Pack to the computer. This
section explains the installation and removal of the High Capacity 2nd
Battery Pack.
Connecting the High Capacity 2nd Battery Pack
Follow the steps below to connect the computer to the High Capacity 2nd
Battery Pack.
1. Turn the computer’s power off.
2. Disconnect all cables connected to the computer.
3. Close the LCD display panel and turn the computer upside down.
4. Open the latches on the High Capacity 2nd Battery Pack and fit a tab on
the battery into the docking hole on the underside of the computer.
Seating the High Capacity 2nd Battery Pack
5. Close the latches to secure the High Capacity 2nd Battery Pack to the
computer.
Before you connect the High Capacity 2nd Battery Pack, make sure you
turn off the computer and disconnect the AC Adaptor and any other
external devices.
