2-8 User’s Manual
The Grand Tour
Front with the display open
This section shows the front of the computer with the display open. Refer to
the appropriate illustration for details. To open the display, push the display
latch on the front of the display and lift up. Position the display at a
comfortable viewing angle.
The front of the Touch Pad model with the display open
Display screen
Stereo speaker
(Right)
Touch Pad control
buttons
Touch Pad
Power button
Display hinge
Stereo speaker
(Left)
Front operation panel
(eleven buttons)
Indicators(2)
Display hinge
Volume control
Microphone
LCD Sensor switch
(Not shown)
Display hinges The display hinges hold the display screen at
easy-to-view angles.
Display screen The LCD displays high-contrast text and
graphics. The computer’s WXGA+ screen
consists of 1440 × 900 pixels. Refer to Appendix
B, Display Controller and Modes .
When the computer operates on the AC adaptor
the display screen’s image will be somewhat
brighter than when it operates on battery power.
The lower brightness level is intended to save
battery power.
Microphone The built-in microphone lets you record sounds
into your applications. Refer to the Sound
System section in Chapter 4, Operating Basics.
