User’s Manual 2-2
The Grand Tour
Left side
Figure 2-2 shows the computer’s left side.
Figure 2-2 The left side of the computer
* The availability of this feature depends on the model you purchased
Cooling vents
Security lock
PC card slot *
External monitor port Wireless communication
switch *
Wireless communication
switch indicator *
USB port
i.LINK(IEEE1394)port *
External monitor
port
This 15-pin port lets you connect an external
video display.
Cooling vents Cooling vents help CPU keep from overheating.
Do not block the cooling vents. Also keep foreign objects out of them. A pin
or similar object can damage the computer’s circuitry.
Wireless
communication
switch
Slide this switch to the left to turn off Wireless
LAN functions. Slide it to the right to turn on the
functions.
The availability of this feature depends on the
model you purchased.
Wireless
communication
switch indicator
The Wireless Communication switch indicator
glows orange when the Wireless LAN function is
on.
The availability of this feature depends on the
model you purchased.
Universal Serial Bus
(USB 2.0) port
A Universal Serial Bus port is on the left side.
The port comply with the USB 2.0 standard,
which enables data transfer speeds 40 times
faster than the USB 1.1 standard (The ports also
support USB 1.1.).
Keep foreign objects out of the USB connectors. A pin or similar object can
damage the computer’s circuitry.
