03 connecting the units – Pioneer GM-6500F User Manual
Page 11
2
Attach lugs to wire ends.
Use pliers, etc., to crimp lugs to wires.
1 Lug (sold separately)
2 Speaker wire
3
Connect the speaker wires to the
speaker output terminals.
Fix the speaker wires securely with the term-
inal screws.
1 Terminal screws
2 Speaker wires
3 Speaker output terminals
En
11
English
Section
03
Connecting the units
