Parts supplied
Parts marked (*) are pre-installed.
The navigation unit Holder*
Side bracket*
(2 pcs.)
Binding screw
(5 mm × 6 mm)
(8 pcs.)
Flush surface screw
(5 mm × 6 mm)
(8 pcs.)
Frame
Screw*
(3 mm × 6 mm)
(8 pcs.)
Screw for fixing the
side bracket*
(5 mm × 6 mm)
(4 pcs.)
Trim ring Double-ended screw
Rubber bush
