Upgrades

Bottom Drives - 9

If you are installing a 50-pin drive:

s

Warning:

Before completing this procedure, you must

terminate the 50-pin drive you are installing. Failure to do

so can severely damage the computer’s logic board.
6 Remove the terminator from the 50-pin SCSI cable.
7 Feed the cable down through the hole in the upper drive

chassis, similar to the routing of the Ultra Wide SCSI

cable shown in the previous graphic.

8 Connect the end of the 50-pin SCSI cable to the

terminated

lower hard drive.

Note:

If you attach more than one terminator to the

internal SCSI interface, the computer’s logic board may

be severely damaged.
