Take Apart

Logic Board - 90

Note:

Remove the processor card and DRAM, VRAM (Power

Macintosh 8600/200), and cache DIMMs (Power Macintosh

8600/200) before returning the board to Apple. Do NOT

remove the ROM SIMM. Refer to the Parts Database to

identify the ROM SIMM and DRAM, VRAM, and cache DIMMs.

Replacement Note:

Reinstall any PCI cards that may have

been removed and for WS 9650 machines, follow the

procedure on the next page for reconnecting the Ultra Wide

SCSI cable.
