751/601 2-5
Control panel/touch panel 2
2.2.2 Display and operation of the left panel
In the left panel of the touch panel, job status and settings can be displayed using the keys. The following are
the keys that appear in the left panel in User Box mode.
Job List
Queued operation, such as saving document data to a user box and printing/sending documents, is called a
job. Touch [Job List] to display the jobs being processed.
Indicates that an external memory is installed.
Icon Description
1
2
3
4
No. Part Name Description
1 [Job List] Jobs that are being processed and the job history can
be checked.
2 [Check Job] Information on the selected user box, scan, printing
and transmission settings of documents can be
checked.
3 [Preview] Saved document image can be previewed.
4 [Detail] Information on the selected document can be
checked.
