751/601 9-4
PageScope Web Connection 9
9.1.4 Structure of pages
The pages of PageScope Web Connection are constructed as shown below.
1
3
2
4 5 6 7
10
9
8
12
11
No. Part Name Description
1 Konica Minolta logo Click the logo to visit the Konica Minolta Web site at
the following URL.
http://konicaminolta.com
2 PageScope Web Connection logo Click the logo to display the version information for
PageScope Web Connection.
3 Logon user name Displays the icon of the current mode and the name
of the user who is logged on (public, administrator,
user box administrator, registered user or account).
Click the user name to display the name of the user
who is logged on.
4 Status display Displays icons and messages indicating the status of
the printer and scanner sections of the machine. If an
error occurred, click the icon to display the error in-
formation (consumables, paper trays and registered
user information) so that the status can be checked.
5 Message display Displays the operating status of the machine.
6 [Logout] button Click to log off from the current mode.
7 [Change Password] button Click to go to the Change User Password page. (Re-
fer to
"Information" on page 9-11 .) This button ap-
pears only in User mode when a registered user is
logged on.
8 Help Click to display the page specified as the online man-
ual Web page. For details on specifying the Web
page, refer to
"Information" on page 9-11 .
9 [Refresh] button Click to update the displayed page.
10 Tabs Select the category of the page to be displayed. The
following tabs are displayed in User mode.
Information
Check Job
User Box
Direct Print
Store Address
11 Menu Information and settings for the selected tabs are list-
ed. The menu that appears differs depending on the
tab that is selected.
12 Information and settings Displays details of the item selected in the menu.
