3. Remove the front bezel by releasing the three plastic tabs 1 on the left side and pulling the front
bezel outward.
Figure 13. Removing the front bezel
4. To reinstall the front bezel, align the other three plastic tabs on the right side of the front bezel with
the corresponding holes in the chassis, then pivot the front bezel inward until it snaps into position
on the left side.
5. Go to “Completing the parts replacement” on page 90.
Locking or unlocking the hard disk drive side door
Attention:
Do not open your server or attempt any repair before reading and understanding the Safety Information and the
Warranty and Support Information on the ThinkServer Documentation DVD that came with your product, and
“Guidelines” on page 21. To obtain a copy of the publications, go to:
http://www.lenovo.com/support
This section provides instructions on how to lock or unlock the hard disk drive side door.
