Front view – Lenovo THINKSERVER TD230 User Manual
Page 19
Chapter 4. Locating parts, controls, LEDs, and connectors
This chapter provides information to help you locate your server parts, controls, light-emitting diodes
(LEDs), and connectors.
Front view
Figure 1 “Front view of the server” on page 9 shows the LEDs and parts on the front of the server.
Figure 1. Front view of the server
1
Power LED
4
System status LED
2
Hard disk drive status LED
5
Front door lock
3
Ethernet status LED
6
Logo plate
© Copyright Lenovo 2010, 2013
9
