Function fittings and flow controls, Fit-3-9, T15 push-in flow regulators – Norgren Flow Controls User Manual
Page 9: Flow vs turns at 6 bar - flow in dm3/s anr
Littleton, CO USA
Phone 303-794-2611
www.norgren.com
FIT-3-9
Function Fittings and Flow Controls
* Available in collet system
** C measured in dm3/(s.bar) Cv measured in US gal/min
Metric
A
B
C
D
E
F
ØG
T15P0003 0.12 (3)
0.51 (13)
0.67 (17)
1.81 (46) 0.51 (13)
M10x1
0.09 (2)
T15P0004
0.16(4)
0.51 (13)
0.67 (17)
1.81 (46) 0.51 (13)
M10x1
0.09 (2)
T15P0005
0.20(5)
0.75 (19)
0.98 (25)
1.93 (49) 0.59 (15)
M12x1
0.14 (4)
T15P0006
0.24(6)
0.75 (19)
0.98 (25)
2.17 (55) 0.59 (15)
M12x1
0.14 (4)
T15P0008
0.31(8)
0.83 (21)
1.06 (27)
2.58 (66) 0.71 (18) M14x1.5 0.14 (4)
T15P0010 0.39(10)
1.04 (27)
1.34 (34)
3.02 (77) 0.94 (24) M20x1.5 0.17 (4)
T15P0012 0.47(12)
1.12 (29)
1.42 (36)
3.64 (93) 0.94 (24) M20x1.5 0.17 (4)
Inch
A
B
C
D
E
F
ØG
T15Y0001
1/8
0.51 (13)
0.67 (17)
1.81 (46) 0.51 (13)
M10x1
0.09 (2)
T15Y0002
5/32
0.51 (13)
0.67 (17)
1.81 (46) 0.51 (13)
M10x1
0.09 (2)
T15Y0003
3/16
0.75 (19)
0.98 (25)
1.93 (49) 0.59 (15)
M12x1
0.14 (4)
T15Y0004
1/4
0.75 (19)
0.98 (25)
2.17 (55) 0.59 (15)
M12x1
0.14 (4)
T15Y0005
5/16
0.83 (21)
1.06 (27)
2.58 (66) 0.71 (18) M14x1.5 0.14 (4)
T15Y0006
3/8
1.04 (27)
1.34 (34)
3.02 (77) 0.94 (24) M20x1.5 0.17 (4)
T15Y0007
1/2
1.12 (29)
1.42 (36)
3.64 (93) 0.94 (24) M20x1.5 0.17 (4)
T15
Push-In Flow Regulators
T-15
Inch
Metric
Maxi regulated
Free flow
Tube
Model
Tube
Model
flow factor Cv**
factorCv**
oz (kg)
1/8"
T15Y0001 3
mm
T15P0003
0.3
0.3
.46
(0.013)
5/32"
T15Y0002
4 mm
T15P0004
0.45
0.45
.46 (0.013)
3/16"
T15Y0003*
5 mm
T15P0005*
0.85
0.85
1.13 (0.032)
1/4"
T15Y0004
6 mm
T15P0006
1.3
1.3
.99 (0.028)
5/16"
T15Y0005
8 mm
T15P0008
2.2
2.2
1.66 (0.047)
3/8"
T15Y0006
10 mm
T15P0010
2.9
3.2
3.28 (0.093)
1/2"
T15Y0007*
12 mm
T15P0012*
5.4
5.4
.50 (0.0143)
0 1
2
3
4
5
6
7
8
9
10
11 12
13 14
Flow
0
1
2
3
4
5
6
7
8
9
10
dm
3
/s
0
2.1
4.2
6.4
8.5
10.6
12.7
14.8
17.0
19.0
21.2
scfm
Flow
Turns
0
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
5
10
15
20
25
30
35
40
0
10.6
21.2
31.8
42.4
53.0
63.6
74.2
84.8
Flow
dm
3
/s
scfm
Flow
Turns
T15-0D12-1/2
T15-0D10-3/8
T15-0D8-5/16
T15-0D6-1/4
T15-0D5-3/16
T15-0D4-5/32
T15-0D3-1/8
Flow vs turns at 6 bar - flow in dm3/s ANR
