Val- 34, Valve manifolds vs26 series, Valves – Norgren VS26 Series Valve Manifolds User Manual
Page 9: Single station sub-base
Valves
www.norgren.com/usa
VAL-
34
Valve Manifolds VS26 Series
Plug-in Mini ISO Valves
2x2/2, 2x3/2, 5/2 and 5/3 valves, ISO 15407-2, Size 26 mm
Connector type: M12
Pin no.
Function
1
not used
2
Signal for solenoid 12
3
Common for solenoid 12 and 14
4
Signal for solenoid 14
3
2
4
1
Pin assignment (acc. VDMA 24571)
Dimensions in inches (mm)
Model
Description
Ports 1, 3 & 5
Ports 12/14 & 82/84
Ports 2 & 4
Connector type
VS2672510-RG00
Single station sub-base for 24V DC
NPTF1/4
NPTF1/8
NPTF1/4
M12
VS2672511-RG00
Single station sub-base for 24V DC and 115V AC
NPTF1/4
NPTF1/8
NPTF1/4
NPTF1/2 conduit
VS2672510-BG00
Single station sub-base for 24V DC
G1/4
G1/8
G1/4
M12
Single station sub-base
4.49 (114)
82/84 2
12/14
4
3.76 (95.5)
2.93 (74.5)
2.22 (56.5)
1.18 (30)
0.59
(15)
0.85 (21.5)
0.93 (23.5)
0.96 (24.5)
1/2 NPTF
0.63
(16)
5
3
1
0.53
(13.5)
1.81 (46)
3.0 (76)
A
A
1.36
(34.5)
1.65
(42)
0.18
(4.5)
0.14
(3.5)
0.73
(18.5)
2.07 (52.5)
5
1
3
0.53
(13.5)
0.87(22)
1.30
(33)
3.44 (87.5)
2.85 (72.5)
3.64 (92.5)
4.45 (113)
1.30 (33)
3.0 (76)
5.61 (142.5)
A
0.55
(14)
M 12
0.69
(17.5)
1.73 (44)
2.44 (62)
3.27 (83)
4.0 (101.5)
A
82/84 2
12/14
4
2.56 (65)
3.34 (85)
4.13 (105)
4.94 (125.5)
6.10 (155)
3.44 (87.5)
1.30
(33)
1.10
(28)
0.85
(22)
0.85 (21.5)
0.93 (23.5)
0.96 (24.5)
0.59
(15)
Connector type: NPTF1/2 Conduit with flying leads
Wiring information
Wire color
Function
Green
Earth
Yellow
Signal for solenoid 12
Black
Common for solenoid 12 and 14
Red
Signal for solenoid 14
