VAL- 28
Valve Manifolds VS26 Series
Plug-in Mini ISO Valves
2x2/2, 2x3/2, 5/2 and 5/3 valves, ISO 15407-2, Size 26 mm
Model Function Actuation Pilot Pilot pressure Operating Manual Voltage
2 x 3/2 supply psi pressure psi (bar) override
VS26SA11DF313A NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Push only 24V DC 1.2W
VS26SA11DF318A NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Push only 115V AC 1.5VA
VS26SA11DF213A NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Push & turn 24V DC 1.2W
VS26SA11DF218A NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Push & turn 115V AC 1.5VA
VS26SA11DF513A NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Extended, push only 24V DC 1.2W
VS26SA11DF518A NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Extended, push only 115V AC 1.5VA
VS26SA22DF313A NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push only 24V DC 1.2W
VS26SA22DF318A NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push only 115V AC 1.5VA
VS26SA22DF213A NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push & turn 24V DC 1.2W
VS26SA22DF218A NC Sol/Spring External 25 [1.7] + (7.3 [0.5] x op. press.) 0 to 145 (0 to 10) Push & turn 115V AC 1.5VA
VS26SA22DF513A NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Extended, push only 24V DC 1.2W
VS26SA22DF518A NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Extended, push only 115V AC 1.5VA
VS26SB11DF313A NO Sol/Spring Internal - 36 to 145 (2.5 to 10) Push only 24V DC 1.2W
VS26SB11DF318A NO Sol/Spring Internal - 36 to 145 (2.5 to 10) Push only 115V AC 1.5VA
VS26SB11DF213A NO Sol/Spring Internal - 36 to 145 (2.5 to 10) Push & turn 24V DC 1.2W
VS26SB11DF218A NO Sol/Spring Internal - 36 to 145 (2.5 to 10) Push & turn 115V AC 1.5VA
VS26SB11DF513A NO Sol/Spring Internal - 36 to 145 (2.5 to 10) Extended, push only 24V DC 1.2W
VS26SB11DF518A NO Sol/Spring Internal - 36 to 145 (2.5 to 10) Extended, push only 115V AC 1.5VA
VS26SB22DF313A NO Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push only 24V DC 1.2W
VS26SB22DF318A NO Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push only 115V AC 1.5VA
VS26SB22DF213A NO Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push & turn 24V DC 1.2W
VS26SB22DF218A NO Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push & turn 115V AC 1.5VA
VS26SB22DF513A NO Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Extended, push only 24V DC 1.2W
VS26SB22DF518A NO Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Extended, push only 115V AC 1.5VA
VS26SC11DF313A NO/NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Push only 24V DC 1.2W
VS26SC11DF318A NO/NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Push only 115V AC 1.5VA
VS26SC11DF213A NO/NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Push & turn 24V DC 1.2W
VS26SC11DF218A NO/NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Push & turn 115V AC 1.5VA
VS26SC11DF513A NO/NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Extended, push only 24V DC 1.2W
VS26SC11DF518A NO/NC Sol/Spring Internal - 36 to 145 (2.5 to 10) Extended, push only 115V AC 1.5VA
VS26SC22DF313A NO/NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push only 24V DC 1.2W
VS26SC22DF318A NO/NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push only 115V AC 1.5VA
VS26SC22DF213A NO/NC Sol/Spring External 25 + (0.5 x op. press.)) 0 to 145 (0 to 10) Push & turn 24V DC 1.2W
VS26SC22DF218A NO/NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Push & turn 115V AC 1.5VA
VS26SC22DF513A NO/NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Extended, push only 24V DC 1.2W
VS26SC22DF518A NO/NC Sol/Spring External 25 + (0.5 x op. press.) 0 to 145 (0 to 10) Extended, push only 115V AC 1.5VA
2x3/2 Double solenoid actuated Softseal valves flow = 1.27 Cv (1250 l/min)
Valve functions designations:
NO = Normally open
NC = Normally closed
