Norgren VS18 Series Valve Islands - Manual (Page 9)

A B A A B
B
A
3-042
Base accessories
4
1
2
Allows individual exchange of valve while valve island is
pressurised by port 1.
Flow restricted to max. 240 l/min.
Symbol MODELS Description
VS1872403-KF00 VS1872402-AF00 Intermediate supply / exhaust manifold (ISEM), port size G1/8
VS1872404-KF00 Blanking plate for blocking of unused stations (supplied with gasket)
MODELS Description
Single valve shut-off plate
Single valve shut-off plate
supplied with gasket
98,5
20 16
80
65
43
9,5
8
10 11
11
10
9 Single valve shut-off plate
Intermediate supply/exhaust manifold
Blanking plate
120,5
VS1872405-KF00
VS1872402-AF00 G1/8
B
A
Multi pressure Dual pressure
Pressure 1 Pressure 1 Pressure 2
Pressure 2
Pr
es
sur
e
3
Pr
es
sur
e
4
MULTI PRESSURE CONFIGURATIONS
A
Blanking disc kit Type Type
Suitable for ports
1, 3 and/or 5
Intermediate supply /
exhaust manifold (ISEM)
11
4
15,5
9
VS18 SERIES VALVE ISLANDS Plug-in Mini ISO Valves
2 x 2/2, 2 x 3/2, 5/2 & 5/3 valves, ISO 15407-2 - 18 mm
