Flow regulator sandwich plate
3 5
Symbol MODELS Description
VS1872401-KF00 Flow regulator supplied with gasket,
dual regulation of exhaust ports 3 & 5
Sandwich plate with additional pressure port 1
4 2
5 3
1 1e
Symbol MODELS Description
VS1872428-KF00 Sandwich plate with additional
pressure port 1 (G1/8), supplied
with gasket
119
20,5
119
7
7 Flow regulator plate 7 Sandwich plate with additional
pressure port 1
Flow characteristics
Dual regulation of exhaust ports 3 & 5
Flow: port 1 > 2 & 1 > 4: remains unchanged.
Flow measured at 6 bar inlet, pressure drop 1 bar.
Exhaus
t fl
ow
(ports 3 + 5)
0
50
100
150
200
250
300
350
400
450
500
550
600
0 1 2 3 4 5 6 7 8 9 10 11 12
Number of turns from closed
114
54,5
15,5
9,5
8
1 1
Port 3
Port 5
