Norgren VS18 Series Valve Islands - Manual (Page 11)

3-044
D-Sub connector 44-pin 1)
M23 connector 19-pin
1 White Solenoid 8-a 14 8
2 Brown (thin) Solenoid 6-a 14 6
3 Green Solenoid 4-a 14 4
4 Yellow Solenoid 2-b 12 2
5 Grey Solenoid 2-a 14 2
6 Blue (thick) Common – –
7 Blue (thin) Solenoid 1-b 12 1
8 Red Solenoid 3-b 12 3
9 Black Solenoid 5-b 12 5
10 Violet Solenoid 7-b 12 7
11 Grey/Pink Solenoid 7-a 14 7
12 Yellow/Green Earth – –
13 White/Green Solenoid 6-b 12 6
14 Brown/Green Solenoid 4-b 12 4
15 White/Yellow Solenoid 1-a 14 1
16 Yellow/Brown Solenoid 3-a 14 3
17 Pink Solenoid 5-a 14 5
18 Red/Blue Solenoid 8-b 12 8
19 Brown (thick) NOT USED – –
1 White Solenoid 1–a 14 1
2 Brown Solenoid 2–a 14 2
3 Green Solenoid 3–a 14 3
4 Yellow Solenoid 4–a 14 4
5 Grey Solenoid 5–a 14 5
6 Pink Solenoid 6–a 14 6
7 Blue Solenoid 7–a 14 7
8 Red Solenoid 8–a 14 8
9 Black Solenoid 9–a 14 9
10 Violet Solenoid 10–a 14 10
11 Grey/Pink Solenoid 11–a 14 11
12 Red/Blue Solenoid 12–a 14 12
13 White/Green Solenoid 13–a 14 13
14 Brown/Green Solenoid 14–a 14 14
15 White/Yellow Solenoid 15–a 14 15
16 Yellow/Brown Solenoid 1–b 12 1
17 White/Grey Solenoid 2–b 12 2
18 Grey/Brown Solenoid 3–b 12 3
19 White/Pink Solenoid 4–b 12 4
20 Pink/Brown Solenoid 5–b 12 5
21 White/Blue Solenoid 6–b 12 6
22 Brown/Blue Solenoid 7–b 12 7
23 White/Red Solenoid 8–b 12 8
24 Brown/Red Solenoid 9–b 12 9
25 White/Black Solenoid 10–b 12 10
26 Brown/Black Solenoid 11–b 12 11
27 Grey/Green Solenoid 12–b 12 12
28 Yellow/Grey Solenoid 13–b 12 13
29 Pink/Green Solenoid 14–b 12 14
30 Yellow/Pink Solenoid 15–b 12 15
31 Green/Blue Solenoid 16–a 14 16
32 Yellow/Blue Solenoid 16–b 12 16
33 – NOT USED – –
34 – NOT USED – –
35 – NOT USED – –
36 – NOT USED – –
37 – NOT USED – –
38 – NOT USED – –
39 – NOT USED – –
40 – NOT USED – –
41 – NOT USED – –
42 – NOT USED – –
43 Blue/Black 3) Common – –
44 Red/Black 3) Common – –
VS18 SERIES VALVE ISLANDS Plug-in Mini ISO Valves
2 x 2/2, 2 x 3/2, 5/2 & 5/3 valves, ISO 15407-2 - 18 mm
Wire colour Socket Pilot Station Wire colour Socket Pilot Station Pin no. Pin no.
1) According to DIN 47100
3) The Norgren D-Sub 44-pin cables do not have 44 wires, but only 34 wires. Therefore,
the wires associated with pins 1 through 32 are according to DIN 47100, wires 43 & 44
differ from the standard and are coloured in green/black and yellow/black.
