3-038
Manual override set-
up kit Spare valve
identification labels
1)
V10009-C00 (35 x 7,5 mm) V70531-KA0 VS1872405-KF00 (Ports 1, 3, 5) VS2672906-KG00 VS2672905-KG00 (10 pcs) VS2672914-KG00
V10592-C01 (35 x 15 mm) VS1872406-KF00 (Port 12/14)
DIN-rail
mounting kit Blanking disc to
modular sub-base DIN EN 50 022
rail (1 metre)
VS1872402-AF00 (G1/8) VS1872404-KF00
Blanking plate Intermediate supply /
exhaust manifold (ISEM)
Base accessories
ACCESSORIES
1) When purchasing assembled valve islands from Norgren, valve identification labels are already included.
2) When V40/V41 valves are fitted on VS18 bases.
Blanking plug for
base connector hole
2)
Single valve
shut-off plate
VS1872400-KF10 (Port 1) VS1872400-KF40 (Ports 2+4) VS1872401-KF00 (Ports 3+5) VS1872428-KF00 (G1/8) VS1872403-KF00 (Port 1)
VS1872400-KF20 (Port 2)
VS1872400-KF30 (Port 4)
Double pressure
regulator plate Flow regulator plate Single pressure
regulator plate
Sandwich plates
Sandwich plate with
additional pressure port 1
2x2/2, 2x3/2, 5/2 & 5/3 Double
solenoid pilot valve
VS18****DF*1*A 5/2 Single solenoid pilot valve
Mechanical spring return
VS18*5*7DF*1*A
8 8
M 3 M 3
41 41
5
,5
5,5 37
,5
37,5
52
,5
52,5
101 101
1
2
,5
12,5
1
9
19
1 1
8
M 3
120
5,5 37,5
52,5
12,5
19
1
VALVE DIMENSIONS
1 Manual override
VS18 SERIES VALVE ISLANDS Plug-in Mini ISO Valves
2 x 2/2, 2 x 3/2, 5/2 & 5/3 valves, ISO 15407-2 - 18 mm
