MSI X2-109 v2 User Manual
Page 51
2-31
Hardware Setup
3. Mount the L-shaped bracket onto the outer channel.
4. Mount the slides to the vertical racks.
Type A
M4 screw
M5 screw
Type B
Type C
M5 screw
FRONT
BACK
washer
black screw
U s e b l a ck r ou n d he a d
screws.
shall be in flush position
9265v1.0-2.p65
2008/5/15, 上午 11:44
31
