M S-9265 Server
1-8
System Management
H8S BMC chip and MSI iConsole AP support IPMI 2.0
BMC Chip
- H8S 200-pin
- Host hardware interface: LPC interface
- Host software interface: KCS interface
Memory Size
- 256 X 16 Bits SRAM
Key Features
- IPMI 2.0 compliant
- Out-of-band LAN based management using RMCP
- FRU/SEL access
- Remote out-of-band alerts
- Event log
- Ability to update firmware inband unattended
- Remote access security (MD5)
- Out-of-band environmental monitoring and alerting
- Secure remote power control and system reset over Serial or
shared NIC (RMCP)
- Supports onboard I2C Winbond 83793G & Winbond 83627 to
extend hardware monitor feature
- Supports ASR (Automatic Server Restart)
System Management
- Three SMBus 2.0 (I2C)
- One SMBus for Intel ESB2E
- One SMBus for IPMB
- One SMBus for Winbond 83793G & W inbond 83627
- CPU fan speed control dependent on system temperature
- System fan speed control dependent on system temperature
Sensor Management
- Monitored Voltage: 12V, 5V, 3V, VBAT, VTT, Vcore, -12V
- Monitored Fan: 6 x System Fan, 2 x CPU Fan
