Rear view rear bezel – MSI X2-109 v2 User Manual
Page 15
1-5
Getting Started
Rear View
Rear Bezel
v
Rear Bezel LEDs
1
PS/2 Keyboard/Mouse Connector
2
USB Ports
3
Serial Port
4
VGA Port
5
LAN Jacks
1
2
3
4
5
LED
Color
LED State
Condition
Off
LAN link is not established.
Orange
On (steady state)
LAN link is established.
On (brighter & pulsing)
The computer is communicating with another
computer on the LAN.
Green
Off
10 Mbit/sec data rate is selected.
On
100 Mbit/sec data rate is selected.
Orange
On
1000 Mbit/sec data rate is selected.
RJ45 NIC1 /
NIC2 Link /Activity
RJ45 NIC1 /
NIC2 Speed
