1-7
Getting Started
IPMI (Optional)
- Hitachi H8S/2168 IPMI microcontroller
C onnector s
Back Panel
- 1 PS/2 mouse & PS/2 keyboard port
- 1 serial port
- 1 VGA port
- 2 USB 2.0 ports
- 2 RJ-45 Gigabit LAN ports
Onboard Connectors
- 2 USB 2.0 connectors
- 1 serial port connector
- 1 front panel audio connector
- 1 chassis intrusion connector
- 1 TPM connector
- 1 SPI Flash ROM connector (for debugging)
Slots
- 1 PCI-Express x16 slot
- 2 PCI-Express x8 slots (with x4 signal)
- 2 32-bit/33MHz PCI slots
Certification
- Safety: UL, CB, CCC
- EMC: FCC Class A, CE Class A
C has sis
- Form factor: 1U-22"
- Externally swappable HDD bay x 4
- Slim DVD drive bay x 1
- Full height slot x 1
- Chassis dimension: 569 x 430 x 43.5mm
Power Supply
- 500 watt
PFC function: Yes
Form factor: SSI EPS 1U
Safety mark: UL, cUL, TUV, CE-mark, CB
