1. To release the hot-swapping HDD tray, flip open the tray lever and pull the tray
out of the bay.
Hard Disk Drive
2. At the rear of the HDD are four screw holes, two on the right and two on the left
side. At the back of the HDD rack are four identical screw holes as on the HDD.
Place the HDD into the rack and align the screw holes on the HDD with the ones
on the rack. Secure the HDD with four screws supplied by the HDD vendor.
