CS5532/34-BS
20 DS755F3
PERFORM CONVERSION
Function: These commands instruct the ADC to perform either a single, fully-settled conversion or con-
tinuous conversions on the physical input channel pointed to by the pointer bits (CSRP2 -
CRSP0) in the channel-setup register.
MC (Multiple Conversions)
0 Perform a single conversion.
1 Perform continuous conversions.
CSRP [2:0] (Channel Setup Register Pointer Bits)
000 Setup 1
001 Setup 2
010 Setup 3
011 Setup 4
100 Setup 5
101 Setup 6
110 Setup 7
111 Setup 8
D7(MSB) D6 D5 D4 D3 D2 D1 D0
1 MC CSRP2 CSRP1 CSRP0 0 0 0
