CS5484
58
DS981F3
6.6.60 Temperature (T)
–
Page 16, Address 27
Default = 0x00 0000
T contains results from the on-chip temperature measurement.
By default, T uses the Celsius scale and is a two's complement value in the range of -128.0
value128.0
(°C), with the binary point to the right of bit 16.
T can be rescaled by the application using the T
GAIN
and T
OFF
registers.
6.6.61 Total Active Power (P
SUM
)
–
Page 16, Address 29
Default = 0x00 0000
P
SUM
= P1
AVG
+P2
AVG
This is a two's complement value in the range of -1.0
value1.0, with the binary point to the right of the MSB.
6.6.62 Total Apparent Power (S
SUM
)
–
Page 16, Address 30
Default = 0x00 0000
S
SUM
= S1+S2
This is an unsigned value in the range of 0.0
value1.0, with the binary point to the right of the MSB.
6.6.63 Total Reactive Power (Q
SUM
)
–
Page 16, Address 31
Default = 0x00 0000
Q
SUM
= Q1
AVG
+Q2
AVG
This is a two's complement value in the range of -1.0
value1.0, with the binary point to the right of the MSB.
MSB
LSB
-(2
7
)
2
6
2
5
2
4
2
3
2
2
2
1
2
0
.....
2
-10
2
-11
2
-12
2
-13
2
-14
2
-15
2
-16
MSB
LSB
-(2
0
)
2
-1
2
-2
2
-3
2
-4
2
-5
2
-6
2
-7
.....
2
-17
2
-18
2
-19
2
-20
2
-21
2
-22
2
-23
MSB
LSB
0
2
-1
2
-2
2
-3
2
-4
2
-5
2
-6
2
-7
.....
2
-17
2
-18
2
-19
2
-20
2
-21
2
-22
2
-23
MSB
LSB
-(2
0
)
2
-1
2
-2
2
-3
2
-4
2
-5
2
-6
2
-7
.....
2
-17
2
-18
2
-19
2
-20
2
-21
2
-22
2
-23
