CS5484
50
DS981F3
6.6.28 Voltage 2 Sag Duration (V2Sag
DUR
) – Page 17, Address 8
Default = 0x00 0000
Voltage sag duration, V2Sag
DUR
, determines the count of OWR samples utilized to determine a sag event.
These are integers in the range of 0 to 8,388,607 samples. A value of zero disables the feature.
6.6.29 Voltage 2 Sag Level (V2Sag
LEVEL
) – Page 17, Address 9
Default = 0x00 0000
Voltage sag level, V2Sag
LEVEL
, establishes an input level below which a sag event is triggered.
This is a two's complement value in the range of -1.0
value 1.0, with the binary point to the right of the MSB.
Negative values are not used.
6.6.30 Current 2 Overcurrent Duration (I2Over
DUR
) – Page 17, Address 12
Default = 0 x00 0000
Overcurrent duration, I2Over
DUR
, determines the count of OWR samples utilized to determine an overcurrent
event.
These are integers in the range of 0 to 8,388,607 samples. A value of zero disables the feature.
6.6.31 Current 2 Overcurrent Level (I2Over
LEVEL
) – Page 17, Address 13
Default = 0x7F FFFF
Overcurrent level, I2Over
LEVEL
, establishes an input level above which an overcurrent event is triggered.
This is a two's complement value in the range of -1.0
value1.0, with the binary point to the right of the MSB.
Negative values are not used.
MSB
LSB
0
2
22
2
21
2
20
2
19
2
18
2
17
2
16
.....
2
6
2
5
2
4
2
3
2
2
2
1
2
0
MSB
LSB
-(2
0
)
2
-1
2
-2
2
-3
2
-4
2
-5
2
-6
2
-7
.....
2
-17
2
-18
2
-19
2
-20
2
-21
2
-22
2
-23
MSB
LSB
0
2
22
2
21
2
20
2
19
2
18
2
17
2
16
.....
2
6
2
5
2
4
2
3
2
2
2
1
2
0
MSB
LSB
-(2
0
)
2
-1
2
-2
2
-3
2
-4
2
-5
2
-6
2
-7
.....
2
-17
2
-18
2
-19
2
-20
2
-21
2
-22
2
-23
