CS5484

DS981F3

NO_OSC

Disable crystal oscillator (making XIN a logic-level input).
0 = Crystal oscillator enabled (Default)
1 = Crystal oscillator disabled

IZX_CH

Select current channel for zero-cross detect.
0 = Selects current channel 1 for zero-cross detect (Default)
1 = Selects current channel 2 for zero-cross detect

VZX_CH

Selects voltage channel for zero-cross detect.
0 = Selects voltage channel 1 for zero-cross detect (Default)
1 = Selects voltage channel 2 for zero-cross detect

6.6.2 Configuration 1 (Config1) – Page 0, Address 1

Default = 0x00 EEEE

EPG4_ON

Enable EPG4 block.
0 = Disable energy pulse generation block 4 (Default)
1 = Enable energy pulse generation 4

EPG3_ON

Enable EPG3 block.
0 = Disable energy pulse generation block 3 (Default)
1 = Enable energy pulse generation block 3

EPG2_ON

Enable EPG2 block.
0 = Disable energy pulse generation block 2 (Default)
1 = Enable energy pulse generation block 2

EPG1_ON

Enable EPG1 block.
0 = Disable energy pulse generation block 1 (Default)
1 = Enable energy pulse generation block 1

DO4_OD

Allow the DO4 pin to be an open-drain output.
0 = Normal output (Default)
1 = Open-drain output

DO3_OD

Allow the DO3 pin to be an open-drain output.
0 = Normal output (Default)
1 = Open-drain output

DO2_OD

Allow the DO2 pin to be an open-drain output.
0 = Normal output (Default)
1 = Open-drain output

DO1_OD

Allow the DO1 pin to be an open-drain output.
0 = Normal output (Default)
1 = Open-drain output
