Page 61: Onnections
The cable connections required for various configurations are detailed below.
Terminal Connection (DB-25)
Tracer (DCE)
Terminal (DTE)
Number
Name
Number
Name
2 .............. TXD
2 ............. TXD
3 .............. RXD
3 ............. RXD
4 .............. RTS
4 .............. RTS
5 .............. CTS
5 .............. CTS
6 .............. DSR
6 ............. DSR
7 ............ Ground
7 ........... Ground
Personal Computer Connection (DB-9)
Tracer (DCE)
Computer (DTE)
Number
Name
Number
Name
2 .............. TXD
3 ............. TXD
3 .............. RXD
2 ............. RXD
4 .............. RTS
7 .............. RTS
5 .............. CTS
8 .............. CTS
6 .............. DSR
6 ............. DSR
7 ............ Ground
5 ........... Ground
Modem Connection (DB-25)
Tracer (DCE)
Modem (DCE)
Number
Name
Number
Name
2 .............. TXD
3 ............. RXD
3 .............. RXD
2 ............. TXD
4 .............. RTS
5 .............. CTS
5 .............. CTS
4 .............. RTS
6 .............. DSR
20 ............ DTR
7 ............ Ground
7 ........... Ground
A
PPENDIX
A
C
ABLE
C
ONNECTIONS
