COMBINED INTERPOLATION & ON-CHIP ANALOG FILTER RESPONSE
(The filter characteristics and the X-axis of the response plots have been normalized to the sample rate (Fs) and can
be referenced to the desired sample rate by multiplying the given characteristic by Fs.)
Notes: 4. For Single-Speed Mode, the measurement bandwidth is 0.5465 Fs to 3 Fs.
For Double-Speed Mode, the measurement bandwidth is 0.577 Fs to 1.4 Fs.
5. De-emphasis is only available in Single-Speed Mode.
Parameter Min Typ Max Unit
Single-Speed Mode - (4 kHz to 50 kHz sample rates)
Passband
to -0.05 dB corner
to -3 dB corner
0
0 -
- 0.4535
0.4998 Fs
Fs
Frequency Response 10 Hz to 20 kHz -0.02 - +0.08 dB
StopBand 0.5465 - - Fs
StopBand Attenuation (Note 4) 50 - - dB
Group Delay - 9/Fs - s
De-emphasis Error (Relative to 1 kHz) Fs = 32 kHz
(Note 5) Fs = 44.1 kHz
Fs = 48 kHz
-
-
- -
-
- +0.2/-0.1
+0.05/-0.14
+0/-0.22
dB
dB
dB
Double-Speed Mode - (50 kHz to 100 kHz sample rates)
Passband
to -0.1 dB corner
to -3 dB corner
0
0 -
- 0.4621
0.4982 Fs
Fs
Frequency Response 10 Hz to 20 kHz -0.06 - +0.2 dB
StopBand 0.577 - - Fs
StopBand Attenuation (Note 4) 55 - - dB
Group Delay - 4/Fs - s
Passband Group Delay Deviation 0 - 40 kHz
0 - 20 kHz -
- ±1.39/Fs
±0.23/Fs -
- s
s
Quad-Speed Mode - (100 kHz to 200 kHz sample rates)
Frequency Response 10 Hz to 20 kHz
-1 - 0 dB
Group Delay - 3/Fs - s
