CS4341A
16 DS582F2
4. REGISTER QUICK REFERENCE
Addr Function 7 6 5 4 3 2 1 0
0h Mode Control 1 Reserved MC1 MC0 Reserved Reserved AUTOD MCLKDIV Reserved
DEFAULT 0 0 0 0 0 0 0 0
1h Mode Control 2 AMUTE DIF2 DIF1 DIF0 DEM1 DEM0 POR PDN
DEFAULT 1 0 0 0 0 0 1 1
2h Transition and Mixing
Control A = B SOFT ZERO
CROSS
ATAPI4 ATAPI3 ATAPI2 ATAPI1 ATAPI0
DEFAULT 0 0 0 0 0 0 0 0
3h Channel A Volume
Control MUTEA VOLA6 VOLA5 VOLA4 VOLA3 VOLA2 VOLA1 VOLA0
DEFAULT 0 0 0 0 0 0 0 0
4h Channel B Volume
Control MUTEB VOLB6 VOLB5 VOLB4 VOLB3 VOLB2 VOLB1 VOLB0
DEFAULT 0 0 0 0 0 0 0 0
