l Additional Cyclic Value
Byte-No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Format
Value
IEEE-754-
Flieskommazahl
PA-OUT
(FB1)
Status
Status
(FB1)
IEEE-754-
Flieskommazahl
Temperature
(FB2)
IEEE-754-
Flieskommazahl
Additional Cyclic
Value
Status
Status
(FB2)
Status
Status
Fig. 54: Telegram configuration example 1
Example 2 with pressure value and temperature value without additional cyclical value:
l AI (PA-OUT)
l Temperature
l Free Place
Byte-No. 1 2 3 4 5 6 7 8 9 10
Format
Value
IEEE-754-
Flieskommazahl
PA-OUT
(FB1)
Status
Status
(FB1)
IEEE-754-
Flieskommazahl
Temperature
(FB2)
Status
Status
(FB2)
Fig. 55: Telegram configuration example 2
Example 3 with pressure value and additional cyclical value without temperature value:
l AI (PA-OUT)
l Free Place
l Additional Cyclic Value
Byte-No. 1 2 3 4 5 6 7 8 9 10
Status
Status
Status
Status
(FB1)
IEEE-754-
Floating point value
PA-OUT
(FB1)
IEEE-754-
Floating point value
Additional Cyclic
Value
Format
Value
Fig. 56: Telegram configuration example 3
Data format of the output signal
Byte4 Byte3 Byte2 Byte1 Byte0
Status Value (IEEE-754)
Fig. 57: Data format of the output signal
