Min. bending radius at 25 °C/77 °F 25 mm (0.985 in)
-
Diameter approx. 8 mm (0.315 in)
-
Colour Blue
Cable entry/plug 22)
-
External housing l
2 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5
or:
l
1 x cable gland M20 x 1.5, 1 x plug (depending
on version), 1 x blind stopper M20 x 1.5
Spring-loaded terminals for wire cross-sec-
tion up to 2.5 mm² (AWG 14)
Indicating and adjustment module
Voltage supply and data transmission through the sensor
Indication LC display in dot matrix
Adjustment elements 4 keys
Protection rating
-
unassembled IP 20
-
mounted into the sensor without cover IP 40
Materials
-
Housing ABS
-
Inspection window Polyester foil
Voltage supply
Operating voltage
-
Non-Ex instrument 9 … 32 V DC
-
EEx-ia instrument 9 … 24 V DC
-
EEx-id instrument 9 … 32 V DC
Operating voltage with lighted indicating and adjustment module
-
Non-Ex instrument 12 … 36 V DC
-
EEx-ia instrument 12 … 30 V DC
-
EEx-id instrument 12 … 32 V DC
Power supply by DP/PA segment coupler
max. number of sensors 32 (10 with Ex)
22) Depending on the version M12 x 1, according to DIN 43650, Harting, 7/
8" FF.
82 Differential pressure transmitter DPT10 - metal measuring diaphragm • Profibus PA
