In this menu item you select the adjustment unit as well as the unit for
the temperature indication in the display.
To select the adjustment unit (in the example switching over from mbar
to bar), proceed as follows:
1
Push the [OK] button in the measured value display, the menu
overview is displayed.
▶
Basic adjustment
Display
Diagnostics
Service
Info
2
Confirm the menu "Basic adjustment" with [OK], the menu item
"
Unit" will be displayed.
Unit
Unit of measurement
mbar
▼
Temperature unit
°C
▼
3
Activate the selection with [OK] and select "Units of measure-
ment with [->].
4
Activate the selection with [OK] and select the requested unit with
[->]
(in the example bar).
5
Confirm with [OK] and move to position correction with [->].
The adjustment unit is thus switched over from mbar to bar.
Information:
When switching over to adjustment in a height unit (for example for
level measurement), the density also has to be entered.
Proceed as follows to enter the density:
1
Push the [OK] button in the measured value display, the menu
overview is displayed.
2
Confirm the menu "Basic adjustment" with [OK], the menu item
"
Units of measurement" will be displayed.
3
Activate the selection with [OK] and select the requested unit with
[->]
(in the example m).
4
Confirm with [OK], the submenu "Density unit" appears.
Unit of measurement
Density unit
▶
kg/dm³
pcf
5
Select the requested unit, e.g. kg/dm³ with [->] and confirm with
[OK]
, the submenu "Density" appears.
Unit of measurement
