Part sum counter
0 % = +0000
m
3
/s=
100 % = +0000
m
3
/s=
6 Edit with [OK] and set the requested values with [+] and [->].
7 Confirm with [OK] and jump back to the indication of the part sum
counter.
8 Select with [->] the unit of the sum counter, adjust the requested
unit with [->], for example m
3
/s and confirm with [OK].
The setting of the part sum counter is hence terminated, the counting
function is activated.
The procedure of the total sum counter is the same.
This function enables reading out parameter adjustment data as well
as writing parameter adjustment data into the sensor via the indicating
and adjustment module. A description of the function is available in the
operating instructions manual "Indicating and adjustment module".
The following data are read out or written with this function:
l Measured value presentation
l Application
l Adjustment
l Damping
l Linearisation curve
l Leak volume suppression
l Sensor-TAG
l Displayed value
l Scaling unit (Out-Scale unit)
l Positions after the decimal point (scaled)
l Scaling PA/Out-Scale 4 values
l Unit of measurement
l Language
The following safety-relevant data are not read out or written:
l Sensor address
l PIN
Copy sensor data
Copy sensor data?
Basic adjustment
The reset "Basic adjustment" resets the following menu items to the
reset values (see chart):
Copy sensor data
Reset
