6 .6 Menu schematic
Basic adjustment flow
1 ▶ Basic adjustment
Display
Diagnostics
Service
Info
1.1 Sensor address
126
1.1 Application
Flow ▼
1.1 Unit
Unit of measurement
bar ▼
Temperature unit
°C ▼
1.2 Position correction
Offset
DP =
-0.0035 bar
0.0000 bar
1.3 Min. adjustment
000 .0 %
DP
- +
=
0 .0000 bar
0 .0000 bar
1.4 Max. adjustment
100 .00 %
DP
- +
=
0 .5000 bar
0.0000 bar
1.5 Damping
1 s
1.6 Linearisation curve
linear ▼
1.6 Leak volume suppression
Activated ▼
1.7 Sensor-TAG
Sensor
Basic setting level
1 ▶ Basic adjustment
Display
Diagnostics
Service
Info
1.1 Sensor address
126
1.1 Application
Level ▼
1.1 Unit
Unit of measurement
bar ▼
Temperature unit
°C ▼
1.2 Position correction
Offset
DP =
-0.0035 bar
0.0000 bar
1.3 Min. adjustment
000 .0 %
=
0 .0000 bar
0 .0000 bar
1.4 Max. adjustment
100 .00 %
=
0 .5000 bar
0.0000 bar
1.5 Damping
1 s
1.6 Linearisation curve
▶ linear
Cylindrical tank
Spherical tank
User programmable
1.7 Sensor-TAG
Sensor
Differential pressure transmitter DPT10 - metal measuring diaphragm • Profibus PA 55
6 Adjustment with the indicating and adjustment module
