1 2 3 4
3
4
1
2
5
Fig. 40: Connection of the sensor in the housing socket
1 Brown
2 Blue
3 Yellow
4 White
5 Shielding
I2C
Display
1
1 2 5 6 7 8
Fig. 41: Wiring plan external electronics
1 Voltage supply
5 .8 Switch on phase
After DPT10 is connected to voltage supply or after voltage
recurrence, the instrument carries out a self-check for approx. 30
seconds. The following steps are carried out:
Terminal compartment
for sensor connection
Wiring plan external
electronics
Switch on phase
40 Differential pressure transmitter DPT10 - metal measuring diaphragm • Profibus PA
5 Connecting to power supply
37245
-EN
