Serial Computer Interface: RS232 and RS485 (multi-drop networking
for up to 255 displays)
Options:Ethernet LAN adapter
Power: Input: 5A, 35W, 7 VAC
120 VAC OR 230 VAC adapter available
Power Cord Length: 10 Ft. (3m)
Keyboard: Handheld, Eurostyle, IR remote operated
Case Material: Molded plastic
Limited Warranty: One-year parts and labor, factory servicing
Agency Approvals: – 120 VAC Model: Power supply has UL/CSA listing.
– 230 VAC Models: Complies with EN 60950:
1992 (Europe).
– FCC Part 15 Class A
– Marked
Operating Temperature: 32°to 120°F, 0°to 49°C
Humidity Range: 0% to 95% non-condensing
Mounting: Hardware to accommodate ceiling or wall mounting
INDOOR DISPLAY
LEDARRAY
MNS
SERIES
Display Dimensions:
Display Array:
Characters Displayed in one-line (minimum):
Display Memory:
Sizes LEDArray
28.9"L x 2.1"D x 4.5"H
(73.4 cmL x 5.3 cmD x 11.4 cmH)
6.25 lbs (2.13 kg.)
27"L x 2.1"H
(68.6 cmL x 5.3 cmH)
90 x 7 pixels
15 characters
7,000 characters
Case Dimensions:
(With power supply)
Approximate Weight:
Built-in Animations: Cherry Bomb Exploding, Don’t Drink and Drive,
Fireworks, Slot Machine, No Smoking, Running
Animal, Moving Auto, Welcome and Thank You
Real-Time Clock: Date and time, 12 or 24 hour format,
maintains accurate time without power for
up to 30 days typical
Memory Retention: One month typical
Message Capacity: 81 different messages can be stored and displayed
Message Operating
Modes: –25 consisting of: Automode, Hold,
Interlock, Roll (6 directions), Rotate, Sparkle-On,
Twinkle, Spray-on, Slide-Across, Switch, Wipe (6
directions), Starburst, Flash, Snow, Scroll
Condensed Rotate
–Continuous message entry with automatic
centering in any mode
–User programmable logos and graphics
– Five hold speeds
Pixel Size (Diameter): 0.2" (.05 cm)
Pixel (LED)Color: Red
Center-to-Center Pixel
Spacing (Pitch):
0.3" (0.8 cm)
Character Size: 2.1" (4.3 cm)
Character Set: Block (sans serif), decorative (serif),
upper/lower case,, slim/wide
POWER REQUIREMENTS
Signs require 115 VAC input power for the plug-in transformer. Use an Exit Sign branch circuit for power.
Power consumption @ 115 VAC: Approximately 113 ma in standby mode & Approximately 300 ma typical message.
Rev. 1
2
LEDArray Specifications - L.E.D. Mass Notification System
