Light Engineered Displays LD Series - Manual

BUILDINGS
NY
C
MEA LISTED
S TA
TE
OF CALIFO
R N IA
S TA
TE
FIRE MAR S H
A L
109 Portwatch Way Wilmington, N.C. 28412 Phone: (800) 251-2512 Fax: (800) 251-9878
Internet: www.ledinc.com Email: [email protected]
Graphic Annunciators * Water Leak Detection
Fireman’s Smoke Control Panels * ARA Systems
LD
SERIES
SIZE GUIDELINES
ANNUNCIATOR
RECOMMENDED MAXIMUM QUANTITY OF SERIAL LAMP DRIVER CARDS
RECOMMENDED ENCLOSURE SIZE BASED ON REQUIRED POINT QUANTITY
INSTALLED PER ENCLOSURE SIZE
Manufacturer requirements may be different
LD-0
LD-1
LD-2
LD-3
LD-4
MOD-16
2
8
16
24
40
OCTAL
2
16
12
18
24
4180
2
6
12
18
24
SDR-32
2
6
9
12
24
GAD
4
6
12
18
24
RAU
1
2
4
6
10
DDM
0
1
2
4
6
LDM-32
2
4
8
12
16
GDM
2
3
6
9
12
SXR
16
30
50
80
160
OMA-80
0
1
1
2
3
LED640
0
1
3
6
15
MODEL NUMBER
G-1212
LD-0
G-1818
LD-1
LD-2
LD-3
LD-4
MAX TOTAL INDICATORS
30 POINTS
40 POINTS
80 POINTS
80 POINTS
270 POINTS
360 POINTS
720 POINTS
NOTES
ENCLOSURE
1. Floor plans can be enlarged or reduced to accommodate the appropriate enclosure size. Unless a
site plan is required, use a scale size of 1/8” = 1’ or larger to preserve details.
2. As an optional service, in addition to our standard annunciator pricing, we will mount and wire YOUR
serial lamp driver cards. Please call us if your driver card is not listed above.
3. The above quantities and sizes are approximate. Call if you have special requirements.
